Power and Control Cable; 300/500V; 2 to 25 conductors; max. 1,50mm²; PVC/PVC, Flame and oil resistant; +80°C
INNOVTRONIC-OZ EB LIYY-OZ Electronic Control/Command Cable
💡 Add to cart — Immediate purchase. The discount for your volume bracket is automatically applied, and you complete the order online.
📋 Add to quote request Our team will analyze and get back to you with a proposal. Ideal for large volumes, special deadlines, or when you need to add cables that are not available for sale online.
- Intrinsic Safety: Designed to eliminate the risk of ignition in hazardous atmospheres (class “i”).
- Flexible Installation: Ideal for fixed or mobile applications in dry and humid environments, without tensile stress.
- High Resistance: Superior durability against acids, bases, and oils, ensuring continuous and stable operation.
- Fire Protection: Self-extinguishing and flame-retardant, offering an extra layer of safety.
- Reliable Connection: Flexible copper conductors for precise and interference-free data transmission.
- Conductor Material: Bare copper wires, flexible and multi-strand.
- Driver Class: Class 5, in accordance with DIN VDE 0295 and IEC 60228.
- Insulation: PVC.
- Driver Identification: Black wires with white numbering, without the green-yellow conductor, according to DIN VDE 0293.
- External Coating: PVC.
- Coating Color: Blue, RAL 5015.
- Nominal Voltage: Uo/U: 300/500 V.
- Test Voltage: 3 kV.
- Insulation Resistance: Minimum of 20 MΩ x km.
- Operating Temperature:
- Fixed installation: -30 °C to +80 °C.
- Mobile installation: -5 °C to +70 °C.
- Minimum Radius of Curvature (Fixed):
- For diameters up to 12 mm: 5 times the cable diameter.
- For diameters greater than 12 mm: 7,5 times the cable diameter.
- Minimum Radius of Curvature (Mobile):
- Up to 12 mm in diameter: 10 times the cable diameter.
- Up to 20 mm in diameter: 15 times the cable diameter.
- Above 20 mm in diameter: 20 times the cable diameter.
- Behavior around fire: Self-extinguishing and flame retardant, in accordance with IEC 60332-1 standard.
- Standards: According to DIN VDE 0245 and 0250.
Benefits
| Applications
|
| General information | |
|---|---|
| Brand | INNOVCABLE |
| Product type | Control and connection cable for data and pulse transmission, for use in intrinsically safe circuits. |
| Electrical Parameters | |
| Nominal Voltage | Uo/U: 300/500 V. For intrinsically safe systems: < 50 V AC / < 75 V DC. |
| Test Voltage | 3 kV |
| Conductor Resistance | In accordance with DIN VDE 0295 class 5 / IEC 60228 class 5. |
| Insulation Resistance | Minimum of 20 MΩ x km. |
| Current Capacity | According to DIN VDE. |
| Capacitance | Approximately 120 nF/km. |
| Inductance | Approximately 0,65 mH/km. |
| Product Design | |
| Conductor Material | Bare copper wires. |
| Driver Design | Flexible, multi-wire, in accordance with DIN VDE 0295 class 5 and IEC 60228 class 5. |
| Includes protective conductor (ground). | No (without green/yellow conductor). |
| Type of Twist | Twisted veins in layers with optimized pitch. |
| Base Material for Vein Isolation | PVC. |
| Base Material for the External Covering | PVC. |
| Cover Color | Blue (RAL 5015). |
| Road Identification | Black veins with sequential white numbering. |
| Product characteristics | |
| Application Area | Intrinsically safe installations in measurement and control. For fixed installation and flexible applications with free movement. Suitable for dry and humid environments. |
| For continuous bending | Yes, for flexible applications with free movement, without tensile stress and without forced guidance. |
| Minimum Bending Radius (Fixed Installation) | Ø up to 12 mm: 5 x diameter; Ø > 12 mm: 7,5 x diameter. |
| Minimum Radius of Curvature (Constant Motion) | Ø up to 12 mm: 10 x diameter; Ø up to 20 mm: 15 x diameter; Ø > 20 mm: 20 x diameter. |
| Temperature, fixed installation | -30 °C to +80 °C. |
| Temperature, constant movement | -5 °C to +70 °C. |
| Flame retardant | Self-extinguishing and flame retardant according to IEC 60332-1. |
| UV resistant | Requires UV protection for outdoor use. |
| Chemical resistant | Resistant to acids, bases, and some types of oils. |
| Halogen-free | Not specified (generally PVC is not halogen-free). |
| Oil resistant | Yes, it is resistant to specific types of oil. |
| Additional Features | Free from silicone and substances that damage paint. |
| Applicable Standards | |
| General Standard | According to DIN VDE 0245 and 0250. |
| Conductor | DIN VDE 0295 cl. 5 / IEC 60228 cl. 5. |
| Road Identification | DIN VDE 0293. |
| Behavior in Fire | IEC 60332-1. |
| Intrinsic Safety | VDE 0165 (Protection class "i"). |
| Directives | Compliant with RoHS. Does not apply to the Low Voltage Directive 2006/95/EC-CE due to the applicable voltage range. |
| Number of conductors and cross-section (nx mm²) | Outer diameter (mm) | Cable weight (kg/km) |
| X 2 0,75 | 5,5 | 46 |
| X 3 0,75 | 5,8 | 54 |
| X 4 0,75 | 6,6 | 66 |
| X 5 0,75 | 7,5 | 80 |
| X 7 0,75 | 8,1 | 110 |
| X 12 0,75 | 11,2 | 176 |
| X 18 0,75 | 12 | 257 |
| X 25 0,75 | 16,7 | 365 |
| X 2 1 | 5,8 | 53 |
| X 3 1 | 6,3 | 67 |
| X 4 1 | 6,9 | 81 |
| X 5 1 | 7,8 | 103 |
| X 7 1 | 8,7 | 193 |
| X 12 1 | 11,7 | 225 |
| X 18 1 | 14,3 | 344 |
| X 25 1 | 17,5 | 500 |
| X 2 1,5 | 6,6 | 70 |
| X 3 1,5 | 7 | 86 |
| X 4 1,5 | 7,9 | 109 |
| X 5 1,5 | 8,8 | 138 |
| X 7 1,5 | 9,8 | 219 |
| X 12 1,5 | 13,6 | 257 |
| X 18 1,5 | 16,4 | 482 |
| X 25 1,5 | 19,4 | 620 |
